◆Can nail a single nail,two nails,strengthen nails one time.

◆One minute quick change size.Easy operation without experience. ◆Feeder automatic counting,tied into bundles sent.

◆Omron PLC control system,Willenton touch screen.

◆Siemens contacts.

◆Allswith control box using domestic brands.

◆Stapled to the semi-finished products made of only two people place in good operation.Simple operation.Reduced salary.

◆Automatic counting after the segment,the number of sheet can do a good job  of  setting  the  number   of  products(1-99)sub-stack  conveyor  is  sent  to client.

◆The use of touch-screen control,nail away from the touch screen can be

set directly facilitate the operation.

◆Mitsubishi servo control,nail away from the longer and more stable,more accurate.

◆Stud mining the entire set of all production of tool stell imported from Japan,computer gongs Precision machining.

◆Bottom die,the blade made of tungsten steel imported from Japan(wear).

机械速度：450钉/分钟

Machine speed 450 mail/minutes

钉距：30-100mm

Nail distance:30-100mm

钉数：1-99钉

Nail number:1-99nail

钉种：单钉、双钉、加强钉

Nail species:single nailreinforcing row

最小用纸尺寸：300×606mm

Minimum size:300×606mm

最大用纸尺寸：1515×2460mm

Maximum size:1515×2460mm

总马力：6HP

Gross horse power:6HP

机械重量：2000KG

Machine weight:2000KG

送纸台推叠高度：900mm.

Feeding paper table height:900mm

适用纸板：3层/5层瓦楞纸板

Applicable cardboard:3 layer/5 layers of corrugated cardboard

钉线规格：2.0mm×(0.65至0.75mm)17#-18#

Nail line specification:2.0mm×(0.65-0.75mm)17#-18#
