电源Power supply

380V/5OHz

三相四线3 phases-4 lines

功率Power

10kw

不含空压机Not including the air compressor

主机皮带速度Host belt speed

15-30 m/min

卡格纸板组合形式

Clapboard combining form

3×(1~N)

双出In double working station

纵向长刀卡轨道数量

Longitudinal clapboard feeding track number

6

横向短刀卡插纸量

Horizontal clapboard feeding track number

1~12

卡格纸尺寸

Clapboard size

长度(Length)L=120~500mm

纸板厚度Clapboard thickness 1.5~7mm

高度(Height)H=70-250mm

宽度(Width)W=120~450mm(双工位double station)

宽度(Width)W=120~900mm(单工位single station)

卡格间隔(Lattice spacing)C=50~150mm

卡格间隔(Lattice spacing)D=30~150mm

生产效率Working speed

40~60套/分(groups/min)

生产效率与卡格纸尺寸及组合形式有关

Working speed is connected with clapboard size and

clapboard combining form.
